    I was being stupid now I need your help with Banana Plugs

    Hey guys, I recently bought a new power amp that only accepts bare wire, but the cable that i bought were all Banana Plug. Is there such a converter that goes from banana plug to bare wire? Or really small spades?

    Thanks

  2. #2
    Suspended markw's Avatar
    Join Date
    Dec 2001
    Location
    Noo Joisey. Youse got a problem wit dat?
    Posts
    4,659
    What amp do you have that only accepts bare wire?

  3. #3
    Super Moderator Site Moderator JohnMichael's Avatar
    Join Date
    Apr 2005
    Location
    Central Ohio
    Posts
    6,307
    Sadly they did not fully fill out their profile so not much info to go on.
    JohnMichael
    Vinyl Rega Planar 2, Incognito rewire, Deepgroove subplatter, ceramic bearing, Michell Technoweight, Rega 24V motor, TTPSU, FunkFirm Achroplat platter, Michael Lim top and bottom braces, 2 Rega feet and one RDC cones. Grado Sonata, Moon 110 LP phono.
    Digital
    Sony SCD-XA5400ES SACD/cd SID mat, Marantz SA 8001
    Int. Amp Krell S-300i
    Speaker
    Monitor Audio RS6
    Cables
    AQ SPKR and AQ XLR and IC

  4. #4
    AR Newbie Registered Member
    Join Date
    May 2013
    Posts
    2
    Quote Originally Posted by markw View Post
    What amp do you have that only accepts bare wire?
    thanks for the response guys.

    I'm talking about McIntosh MC 7100. One that looks like this
    I was being stupid now I need your help with Banana Plugs-img_0640%5B1%5D.jpg

  5. #5
    Shostakovich fan Feanor's Avatar
    Join Date
    Jun 2002
    Location
    London, Ontario
    Posts
    8,127
    Quote Originally Posted by peppershaker View Post
    thanks for the response guys.

    I'm talking about McIntosh MC 7100. One that looks like this
    Click image for larger version.

Name:	IMG_0640[1].jpg
Views:	62
Size:	90.5 KB
ID:	9357
    Ah-ha! Nice older Mac amp. Yes, I have seen adaptors for these old-fashioned connectors to permit banana plugs.

    Finding these could take some looking around. I might be able to help out; I'll do some checking.

    Are you in Canada? I see a CSA sticker in the picture.

  6. #6
    Shostakovich fan Feanor's Avatar
    Join Date
    Jun 2002
    Location
    London, Ontario
    Posts
    8,127
    Here ya go: enter "screw to banana adaptor" in eBay in the Consumer Electronics category and you'll find examples.

    Name:  $(KGrHqV,!oUE8VqItkp3BPM3TCOctg~~60_1.JPG
Views: 57
Size:  15.0 KB

    Here are a couple for instances ...

    LOT8 Adapter Spade Banana Plug FOR Fisher AMP 8 PCS | eBay

    4pcs Y TO Banana Plug Spade Adapter Marantz Mcintosh Amplifier MC30 MC275 Fork | eBay

  7. #7
    Suspended markw's Avatar
    Join Date
    Dec 2001
    Location
    Noo Joisey. Youse got a problem wit dat?
    Posts
    4,659
    Good find but they look like they could easily be shorted out, what with only that tiny barrier between the terminals.

    Another, possibly cheaper, definitely safer, but much less visually appealing would be to get some stackable banana plugs, insert a short length of wire to attach to the amp, tape up the plug itself, and insert your plugs into the top of these.

    The funny thing is that when these amps were made it was anticipated that we would be using 16 gauge lamp cord, not the fat botique cables they sell today.

  8. #8
    Shostakovich fan Feanor's Avatar
    Join Date
    Jun 2002
    Location
    London, Ontario
    Posts
    8,127
    Quote Originally Posted by markw View Post
    Good find but they look like they could easily be shorted out, what with only that tiny barrier between the terminals.

    Another, possibly cheaper, definitely safer, but much less visually appealing would be to get some stackable banana plugs, insert a short length of wire to attach to the amp, tape up the plug itself, and insert your plugs into the top of these.

    The funny thing is that when these amps were made it was anticipated that we would be using 16 gauge lamp cord, not the fat botique cables they sell today.
    Yep, lamp cord ruled in those days which I remember well. Flimsy, cheap "phono plug" interconnects were considered quite adequate too ... like THESE.

    Any way you slice it those closely spaced terminals pose some shorting risk, whether bare wire, spades, or banana plug adaptors.
